BOSCHVXD-N128H2BK
- Recording Bandwidth: 256 Mbps
- Video Encode: H.265/ H.264
- Recording Resolution : 8.0MP , 5.0MP, 4 .0Mp, 3.0MP, 2.0MP, 1.3MP, 1.0MP, HDMI/VGA simultaneous video output 4K
- Internal HDD: 2 SATA port, up to 10TB capacity
- Support Onvif’
- AI: Face Detection, Face Recognition / Human Detection/Vehicle Detection / License Plate Detection
- Support Cloud Storage
| Model Name | VXD-N128H2BK | |
| Video | Resolution | 8 channel 12MP/24 channel 8MP/32 channel 5MP, 3MP ,2MP(1080P), 1.3MP(960P),1.0MP(720P) |
| Recording Bandwidth | Inputs | 256M |
| Output | 256M | |
| Performance | ||
| Live/Playback | Compression | Audio: G.711A;G.711U Video : H.264/H.264+/H.265/H.265+ |
| Frame rate | 4K:60fps - 4MP:120fps - 2MP:240fps | |
| AI | YES | |
| Event | MD(Sensitivity Level 1~8) | |
| Video loss | ||
| Beep, Email, Push notification to Mobile APP | ||
| Playback function | Fast forward / backward (2x, 4x, 8x,16x) | |
| Slow forward (1/2x, 1/4x, 1/8x,1/16x) | ||
| Playback | Max 16CH playback | |
| Fisheye | Support | |
| UI/Monitoring | Local | UI5.0 |
| WEB | IE10/11 - Safari V12.1 above -Firefox V.52 above Google chrome V.57 above - Edge V.79 above | |
| Mobile viewer | VANTECH PRO | |
| Push N/Atification | YES | |
| Interface | ||
| P/W Reset | Factory Reset : Press 10 seconds | |
| Monitors | VGA | 1（1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080） |
| HDMI 1 | 1（1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 , 3840*2160/EDID） | |
| HDMI 2 | 1（1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080） Async output | |
| Ethernet | 2 RJ45 100/1000 Base-T | |
| USB | USB2.0*1(front) USB3.0*1+USB2.0*1(rear) | |
| Audio out | 1 | |
| E-sata | 1 | |
| HDD | 2 SATA , each HDD up to 10TB | |
| ANR | support | |
| Audio in /line in | 1 | |
| RS485 /RS232 | 1/1 | |
| Alarm Input/out | 16 in /4 out | |
| General | ||
| OSD Language | English/French/Spanish/Portuguese/German/Italian/Greek/Danish/Finnish/Russia/Hebrew/Turkish/Bulgarian/ Arabic/Korean/Japanese/Thai/Hindi/Romanian/Dutch/ Polish/Vietnam | |
| Mechanical design | Dimension (WxDxH) | 380*340*50mm |
| Electrical | Input Voltage/Current | 12V/5A |
| Power consumption (excluding hard disk) | 12W | |
| Environmental | Operating Temperature/Humidity | Temperature : -10°C~+50°C (14°F ~ 122°F) Humidity : Less than 90%RH |
